BS100 Intelligent Battery Station
BS100 Intelligent Battery Station
BS100 Intelligent Battery Station
New
  • SKU:
  • Availability: in stock Many in stock Out of stock You can purchase this product but it's out of stock

BS100 Intelligent Battery Station

$1,919.00
Shipping calculated at checkout.
Shipping Ask about this product
DESCRIPTION

Mission-Ready Battery Management

Battery Turnaround Without the Bottleneck

The BS100 keeps Matrice 400 operations moving by combining fast charging, intelligent battery management and field-ready transport in one compact station.

System Compatibility

The BS100 is designed for the following DJI Matrice 400 system components:

Compatible Aircraft
DJI Matrice 400
Flight Batteries
TB100 and TB100C
Controller Battery
WB37

Key Operating Specifications

Operating Temperature −20 to 40°C Built for cold-weather and summer field operations
AC Input Range 100–240 V Supports common 110 V and 220 V power sources
USB-C Output 65 W Power and connect a compatible remote controller
Station Dimensions 605 × 410 × 250 mm Compact footprint for transport and storage

Four Charging Modes

Choose the Right Priority

Choose the charging behaviour that best matches your mission tempo, available power and noise requirements.

Ready-to-Fly 90% Target

Stops at 90% to reduce turnaround time and return batteries to service sooner.

Standard 100% Target

Charges to 100% when maximum available capacity is the priority.

Fast / Turbo Fastest Turnaround

Recharges a TB100 from 0–100% in approximately 45 minutes at 220 V or 70 minutes at 110 V.

Silent Reduced Noise

Lowers operating noise for indoor staging and noise-sensitive locations.

Built for Field Operations

Intelligent Features That Reduce Downtime

  • Intelligent Charging Sequence Charges TB100 and TB100C batteries sequentially, beginning with the battery closest to full.
  • Automatic Battery Warming When a supported battery is below 5°C, the powered station can warm it automatically before charging.
  • DJI Pilot 2 Diagnostics Use a USB-C connection to view battery data, update firmware and diagnose errors through DJI Pilot 2.
  • Made to Move Integrated storage and 360° omni-directional wheels make the 11.8 kg station easier to organize and move.

Product Details

Specifications and Included Items

Technical Specifications
Model
BS100 Intelligent Battery Station
Supported Batteries
TB100 Intelligent Flight Battery, TB100C Tethered Battery and WB37 Battery
Battery Ports
3 × TB100-class ports and 2 × WB37 ports; TB100 and TB100C charge sequentially
Charging Modes
Ready-to-Fly, Standard, Fast / Turbo and Silent
TB100 Charge Time
Approx. 45 minutes at 220 V in Fast Mode; 70 minutes at 110 V in Fast Mode; 110 minutes in Silent Mode
Input
100–240 V AC, 50–60 Hz, 10 A
TB100-Port Output
Approx. 1,185 W at 100–110 V; 1,474 W at 110–180 V; 2,184 W at 180–240 V
WB37-Port Output
Approx. 52 W
USB-C Output
5 V / 9 V / 12 V / 15 V at 3 A; 20 V at 3.25 A; 65 W maximum
Operating Range
−20°C to 40°C (−4°F to 104°F)
Dimensions
605 × 410 × 250 mm
Weight
Approx. 11.8 kg
In the Box
1× BS100 Intelligent Battery Station Regional accessories and cable packages may vary.
Charging and Safety Notes
For safe operation: place the station on a flat, stable surface and keep the cover open while charging for ventilation. Keep liquids away and use only supported DJI batteries.

Charging times are measured at approximately 25°C and may vary with input voltage, battery temperature, battery condition and operating environment. Always follow current DJI documentation and safety instructions.

Here When You Need Us

Build the Right Battery Setup With Confidence

Whether you are equipping your first Matrice 400 or expanding an existing fleet, our team can help you select the right batteries, understand charging requirements and plan realistic mission turnaround.

Talk With a Product Specialist → Straightforward guidance from an enterprise drone team based in Canada.
